Consul 1-ram inground lift H-Chassis 2.500 kg

SKU: 487801
Category: Single Ram Inground Lifts

H-Chassis for 1 ram inground lift with a capacity of 2.500 kg.

Design features:

H-Beam with 4 aluminium slider plates, adjustable length- and crosswise
Beam painted
Elastomer adapters 20 mm
Fixing material
GS-approved, DIN EN 1493, CE-approved

technical data
PDF (1)

Rated load capacity:	2.500 kg
Lifting height:	ca. 1.862 mm
Pick-up area longitudinal:	1.300 - 1.912 mm
Pick-up area cross:	700 - 1.900 mm
Ascending height / Rest height:	ca. 68 mm

Brochure:

Brochure
